2MN/2N1
1-3-128
U469 Method: [Belt Initialize]
1. Select [Execute].
2. Press the OK key. Transfer belt speed correction starts.
Method:[Belt Check]
1. Select [Mode].
2. Change the setting value using the numeric keys.
3. Select [Execute].
4. Press the OK key. Transfer belt position confirmation starts, and the value is displayed.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
U474 Checking LSU cleaning operation
Description
Provides cleaning LSU by means of the LSU cleaning motor. Also, the cleaning cycle can be
adjusted.
Method
1. Press the OK key.
2. Select the item.
Method: [Execute]
1. Press the OK key. Cleaning the LSU slit glass.
Setting: [Cycle]
1. Change the setting value using numeric keys.
The setting can be changed by 1000 per step.
2. Press the OK key. The value is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Angle Display of cam position
Belt Position Display of belt position
Mode Operational mode
Excute Execution of belt position confirmation
Display Description
Execute Executing the cleaning operation
Cycle Setting the cleaning cycle
Display Description
Setting
range
Initial
setting
Cnt Cleaning cycle 0 to 5000 1000
