Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
1-1-4
1-1-2 Parts names
(1) Machine
Figure 1-1-1
7
8
18
13 10 11
3
4
5
6
1
2
15
16
17
14
12
9
1. Operation panel
2. Indicators
3. Main tray
4. Job separator tray
5. Toner container K
6. Toner container M
7. Toner container C
8. Toner container Y
9. Release button
10. Waste toner box
11. Waste toner tray
12. Front cover
13. Handles
14. Network interface connector
15. USB port
16. USB interface connector
17. Option interface
18. Toner container release lever
