2MN/2N1-1
1-3-31
U033 Checking the operation of the solenoids
Description
Turns each solenoid on.
Purpose
To check the operation of each solenoid.
Method
1. Press the OK key.
2. Select [Motor On] or [Motor Off].
1. Press the OK key.
2. Select the solenoid to be operated.z
3. Press the OK key. The operation starts.
4. To stop operation, press the Back key.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Motor On
Motor is turned on
Motor Off
Motor is turned off
Display Description
Branch Left Feedshift solenoid (FSSOL) is turned on
Branch Exit Feedshift solenoid is turned on
JobSepa JS feedshift solenoid (JSFSSOL) is turned on
ID Clean Cleaning solenoid (CLSOL) is turned on
Bridge Solenoid Bridge solenoid is turned on
Mail box Mail box solenoid is turned on
