2MN/2N1
1-4-96
(21)
Paper conveying
clutch does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Paper conveying clutch and feed PWB 2 (YC5)
Feed PWB 2 (YC1) and engine PWB (YC4)
2. Defective clutch. Replace the paper conveying clutch.
3. Defective PWB. Replace the feed PWB 2 or engine PWB and check for cor-
rect operation (see page 1-5-49).
(22)
MP paper feed
clutch does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP paper feed clutch and relay PWB (YC3)
Relay PWB (YC12) and feed PWB 1 (YC17)
Feed PWB 1 (YC1) and engine PWB (YC6)
2. Defective clutch. Replace the MP paper feed clutch.
3. Defective PWB. Replace the relay PWB, feed PWB 1 or engine PWB and
check for correct operation (see page 1-5-49).
(23)
Pickup solenoid 1,
2 does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Pickup solenoid 1, 2 and feed PWB 2 (YC8)
Feed PWB 2 (YC1) and engine PWB (YC4)
2. Defective solenoid. Replace the pickup solenoid 1 or 2.
3. Defective PWB. Replace the feed PWB 2 or engine PWB and check for cor-
rect operation (see page 1-5-49).
(24)
Feedshift solenoid
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Feedshift and front PWB (YC5)
Front PWB (YC3) and engine PWB (YC7)
2. Defective solenoid. Replace the feedshift solenoid 1 or 2.
3. Defective PWB. Replace the front PWB or engine PWB and check for cor-
rect operation (see page 1-5-49).
(25)
Cleaning solenoid
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Cleaning solenoid and feed PWB 1 (YC10)
Feed PWB 1 (YC1) and engine PWB (YC4)
2. Defective solenoid. Replace the cleaning solenoid.
3. Defective PWB. Replace the feed PWB 1 or engine PWB and check for cor-
rect operation (see page 1-5-49).
(26)
The message
requesting paper to
be loaded is shown
when paper is
present on the cas-
sette.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Paper sensor 1, 2 and feed PWB 2 (YC8)
Feed PWB 2 (YC1) and engine PWB (YC4)
2. Deformed actuator. Check visually and replace if necessary.
3. Defective sensor. Replace the paper sensor 1 or 2.
4. Defective PWB. Replace the feed PWB 2 or engine PWB and check for cor-
rect operation (see page 1-5-49).
Problem Causes Check procedures/corrective measures
