2MN/2N1-1
1-3-132
U901 Checking print counts by paper feed locations
Description
Displays or clears paper feed counts by paper feed locations.
Performs backup when the counters on the engine PWB and PF main PWB do not match.
Purpose
To check the time to replace consumable parts. Also to clear the counts after replacing the con-
sumable parts.
Backup the counter values after completing changing the PF main PWB and the paper feed unit.
Method
1. Press the OK key. The counts by paper feed locations are displayed.
* : When an optional paper feed unit is not installed, the corresponding count is not dis-
played.
Clearing
1. Select the counts to be cleared.
[Cassette3], [Cassette4], [Cassette5], [Cassette6] and [Cassette7] cannot be cleared.
2. Select the counts for all and press [Clear].
3. Press the OK key. The counts is cleared.
Back up
If the paper feeding counters of the engine and the paper feeder do not match, the following mes-
sage will be displayed.
The back up destination will be shown on the list items and 'engine (fixed value)' <-> None <->
'PF (fixed PF value) are displayed.
1. Press the OK key. The counts by paper feed locations are displayed.
Item No. Description
Display Description
MPT MP tray
Cassette1 Cassette 1
Cassette2 Cassette 2
Cassette3 Cassette 3 (paper feeder/large capacity feeder)
Cassette4 Cassette 4 (paper feeder/large capacity feeder)
Cassette5 Cassette 5 (side multi tray/side deck)
Cassette6 Cassette 6 (side paper feeder/side large capacity feeder)
Cassette7 Cassette 7 (side paper feeder/side large capacity feeder)
Duplex Duplex unit
Display Description
Cassette3 Cassette 3 (paper feeder/large capacity feeder)
Cassette4 Cassette 4 (paper feeder/large capacity feeder)
Cassette5 Cassette 5 (side multi tray/side deck)
Cassette6 Cassette 6 (side paper feeder/side large capacity feeder)
Cassette7 Cassette 7 (side paper feeder/side large capacity feeder)
Duplex Duplex unit
To Next Page
