Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1-1
1-3-91
U240 Checking the operation of the finisher
Description
Turns each motor and solenoid of 1000-sheet finisher or 4000-sheet finisher ON.
Purpose
To check the operation of each motor and solenoid of the 1000-sheet finisher or 4000-sheet fin-
isher.
Method
1. Press the OK key.
2. Select the item to be checked.
3. Press the OK key.
Method: [Motor]
1. Select the item to be operated.
2. Press the OK key. The operation starts.
Item No. Description
Display Description
Motor Checking the motor of the document finisher
Solenoid Checking the solenoid of the document finisher
Mail Box Checking the motor of the mailbox
Top Mail Box Checking the motor of the top mailbox
Booklet Checking the motor of the center-folding unit
Display Description
Feed In(H) DF paper entry motor (DFPEM) is turned on at high speed
Feed In(L) DF paper entry motor (DFPEM) is turned on at low speed
Middle(H) DF middle motor (DFMM) is turned on at high speed
Middle(L) DF middle motor (DFMM) is turned on at low speed
Eject(H) DF eject motor (DFEM) is turned on at high speed
Eject(L) DF eject motor (DFEM) is turned on at low speed
Save(H) DF drum motor (DFDRM) is turned on at high speed
Save(L) DF drum motor (DFDRM) is turned on at low speed
Tray DF tray motor (DFTM) is turned on
Staple Move DF slide motor (DFSLM) is turned on
Staple DF staple motor (DFSTM) is turned on
Width Test(A3) DF side registration motor 1, 2 (DFSRM1, 2) is turned on
Width Test(LD) DF side registration motor 1, 2 (DFSRM1, 2) is turned on
Beat DF paddle motor (DFPDM) is turned on
Eject Unlock(HP) DF eject release motor (DFERM) is turned on to home position
Sort Test DF shift motor 1, 2 (DFSFM1, 2) is turned on
EjectUnlock(30) DF eject release motor (DFERM) drive position 30-sheet stack
EjectUnlock(50) DF eject release motor (DFERM) drive position 50-sheet stack
