2MN/2N1-1
1-3-108
U260 Selecting the timing for print counting
Description
Changes the print count timing for the total counter and other counters.
Purpose
To be set according to user request.
Setting
1. Press the OK key.
2. Select the print count timing.
Initial setting:
Eject
3. Press the OK key. The setting is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
U265 Setting OEM purchaser code
Description
Sets the OEM purchaser code.
Purpose
Sets the code when replacing the main PWB and the like.
Setting
1. Press the OK key.
2. Change the setting value using the numeric keys.
3. Press the OK key. The setting is set.
4. Exit the maintenance mode, perform shut-down, and turn the main power switch to off and on
again. Allow more than 5 seconds between Off and On.
Item No. Description
Display Description
Feed When secondary paper feed starts
Eject When the paper is ejected
