U030 Checking the operation of the motors

Description

Drives each motor.

Purpose

To check the operation of each motor.

Method

1. Press the OK key.

2. Select the motor to be operated.

3. Press the OK key. The operation starts.

4. To stop operation, press the Back key.

Completion

Press the Back key. The screen for selecting a maintenance item No. is displayed.

Item No. Description

Display Description

Feed Paper feed motor (PFM) is turned on

DLP(K) Developer motor K (DEVM-K) is turned on

DLP(CMY) Developer motor MCY (DEVM-MCY) is turned on

Fuser Fuser motor (FUM) is turned on

SB(CW) Eject motor (EM) is turned on clockwise

SB(CCW) Eject motor (EM) is turned on counterclockwise

CMY Release Color release motor (CRM) is turned on

JobSepa JS eject motor (JSEM) is turned on

Regist Registration motor (RM) is turned on

Bridge1 BR conveying motor 1 (BRCM1) is turned on

Bridge2 BR conveying motor 2 (BRCM2) is turned on

Belt Meand Transfer motor (TRM) is turned on

Press Release Transfer release motor (TRRM) is turned on

Fuser Release Fuser release motor (FURM) is turned on

DU1 Duplex motor 1 (DUM1) is turned on

DU2 Duplex motor 2 (DUM2) is turned on

Mid Roller Middle motor (RM) is turned on

InnerJobSepa(CW) JS conveying motor (JSCM) is turned on clockwise

InnerJobSepa(CCW) JS conveying motor (JSCM) is turned on counterclock-

wise
