Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1-1
1-2-8
3. Remove tape.
Figure 1-2-10
*: When the finisher has been installed, the job separator tray and the main tray are not needed.
1. Install the main tray included by latching
in two hooks and securing by one
screw.
Figure 1-2-11
Tape
Installing the main tray and job separator tray
Hooks
Pin
Main tray
