Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
1-4-40
2500 Paper feed motor error
After paper feed motor is
driven, the ready signal does
not turn to L within 2 s.
After paper feed motor is sta-
bilized, the ready signal is at
the H level for 1 s continu-
ously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Paper feed motor and feed PWB 2 (YC2)
Feed PWB 2 (YC1) and engine PWB (YC4)
Defective drive
transmission sys-
tem of motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective paper
feed motor.
Replace the paper feed motor.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
2600 PF paper feed motor error
(large capacity feeder)
After PF paper feed motor is
driven, the ready signal does
not turn to L within 2 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF paper feed motor and PF main PWB
(YC16)
Defective drive
transmission sys-
tem of motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective PF paper
feed motor.
Replace the PF paper feed motor.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
2610 PF paper feed motor error
(paper feeder)
After PF paper feed motor is
driven, the ready signal does
not turn to L within 2 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF paper feed motor and PF main PWB
(YC16)
Defective drive
transmission sys-
tem of motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective PF paper
feed motor.
Replace the PF paper feed motor.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Code Contents Causes
Check procedures/
corrective measures
