2MN/2N1
2-4-1
2-4 Appendixes
2-4-1 Appendixes
(1) List of maintenance parts
Maintenance part name
Part No.
Alternative
part No.
Name used in service manual Name used in parts list
Paper feed pulley
PULLEY FEED 302K906350 2K906350
Separation pulley
PULLEY RETARD 302K906360 2K906360
Forwarding pulley
PULLEY PICKUP 302K906370 2K906370
Lower duplex roller
PARTS ROLLER DU LOW SP 302K994470 2K994470
Middle duplex roller
PARTS ROLLER DU MID SP 302K994480 2K994480
Upper duplex roller
PARTS ROLLER DU UP SP 302K994490 2K994490
Eject roller
PARTS ROLLER EXIT SP 302LC94350 2LC94350
Fan filter
PARTS FILTER FAN ASSY(V) SP 302LC94170 2LC94170
Developer filter
FILTER DLP COOLING 302LC33500 2LC33500
Transfer belt filter
PARTS FILTER BELT UNIT(V) SP 302LC94130 2LC94130
Toner filter
FILTER LEFT SIDE 302LC33370 2LC33370
Left filter
FILTER LEFT SIDE 302LC33370 2LC33370
Eject filter
PARTS FILTER EXIT UNIT SP 302K994100 2K994100
