2MN/2N1
1-5-76
(5) Detaching and refitting the left filter
Procedure
1. Remove the left filter cover by releasing
the lever.
2. Remove the left filter.
3. Clean or replace the left filter and refit
the filter.
Figure 1-5-117
Left filter
cover
Left filter
Lever
