Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
1-3-41
U053 Setting the adjustment of the motor speed
Description
Performs fine adjustment of the speeds of the motors.
Purpose
Basically, the setting need not be changed. Modify settings by interlock setting only if faulty
images occur.
Method
1. Press the OK key.
2. Select the item to be adjusted
3. Press the OK key.
*: 55 ppm model only.
Setting: [Motor1]
1. Select the item to be adjusted.
Item No. Description
Display Description
Motor1 Adjustment of drum motor K speeds
Motor2 Adjustment of developer motor K, developer motor MCY, transfer motor,
registration motor and transfer cleaning motor speeds
Motor3
Adjustment of eject motor, fuser motor, BR conveying motor 1/2, paper
feed motor, JS eject motor, middle motor and duplex motor 1/2 speeds
Motor4 Drum motor K speed adjustment in black/white mode
Motor5* Adjustment of developer motor K, transfer motor, registration motor and
transfer cleaning motor speeds in black/white mode
Motor6* Adjustment of eject motor, fuser motor, BR conveying motor 1/2, paper
feed motor, JS eject motor, middle motor and duplex motor 1/2 speeds
in black/white mode
Motor1 Half Adjustment of drum motor K speeds in half speed
Motor2 Half Adjustment of developer motor K, developer motor MCY, transfer motor,
registration motor and transfer cleaning motor speeds in half speed
Motor3 Half Adjustment of eject motor, fuser motor, BR conveying motor 1/2, paper
feed motor, JS eject motor, middle motor and duplex motor 1/2 speeds
in half speed
Motor1 3/4 Adjustment of drum motor K speeds at 3/4 times of line speed
Motor2 3/4 Adjustment of developer motor K, developer motor MCY, transfer motor,
registration motor and transfer cleaning motor speeds at 3/4 times of
line speed
Motor3 3/4 Adjustment of eject motor, fuser motor, BR conveying motor 1/2, paper
feed motor, JS eject motor, middle motor and duplex motor 1/2 speeds
at 3/4 times of line speed
Display Description
Setting
range
Initial setting
45ppm 55ppm
Drum(K) Drum motor K (DRM-K) -5000 to 5000 12 11
