Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
1-4-32
1100 PF lift motor 1 error
(large capacity feeder)
After cassette 3 is inserted,
PF lift sensor 1 does not turn
on within 23 s. This error is
detected 5 times successively.
(Time to detect is 2 seconds
at the second time and later.)
During driving the motor, the
lift overcurrent protective
monitor signal is detected for
200 ms or more 5 times suc-
cessively. However, the first 1
s after PF lift motor 1 is turned
on is excluded from detection.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 1 and PF main PWB (YC7)
Defective drive
transmission sys-
tem of motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective PF lift
motor 1.
Replace the PF lift motor 1.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
1110 PF lift motor 2 error
(large capacity feeder)
After cassette 4 is inserted,
PF lift sensor 2 does not turn
on within 23 s. This error is
detected 5 times successively.
(Time to detect is 2 seconds
at the second time and later.)
During driving the motor, the
lift overcurrent protective
monitor signal is detected for
200 ms or more 5 times suc-
cessively. However, the first 1
s after PF lift motor 2 is turned
on is excluded from detection.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 2 and PF main PWB (YC7)
Defective drive
transmission sys-
tem of motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective PF lift
motor 2.
Replace the PF lift motor 2.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
1140 SD lift motor error
(side deck)
After cassette 5 is inserted,
SD lift sensor does not turn on
within 30 s.
The lock signal of the motor is
detected continuously for 200
ms.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
SD lift motor and SD main PWB (YC8)
Defective drive
transmission sys-
tem of motor.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective SD lift
motor.
Replace the SD lift motor.
Defective SD main
PWB.
Replace the SD main PWB (Refer to the ser-
vice manual for the paper feeder).
Code Contents Causes
Check procedures/
corrective measures
