2MN/2N1
1-2-21
1-2-3 Installing the cassette heater (option)
Cassette heater installation requires the following parts:
Supplied parts of cassette heater set (302K994930):
Supplied parts of cassette heater set (302K994940):
Parts Quantity Part.No.
Cassette heater set (120V) 1 302K994930
Cassette heater set (240V) 1 302K994940
Parts Quantity Part.No.
Cassette heater (120V) 1 302H794620
Wire saddle 3 7YZM610001++H0
Label 1 302KP34220
Connector cover 1 303NF04140
M3 x 8 tap-tight S screw 2 7BB700308H
M4 x 8 tap-tight S screw 1 7BB700408H
Parts Quantity Part.No.
Cassette heater (240V) 1 302H794610
Wire saddle 3 7YZM610001++H0
Label 1 302KP34220
Connector cover 1 303NF04140
M3 x 8 tap-tight S screw 2 7BB700308H
M4 x 8 tap-tight S screw 1 7BB700408H
To Next Page
