2MN/2N1-1
1-2-22
Procedure
1. After confirming the data lamp is turned
off, perform shut-down on the operation
panel, turn power off, and unplug the
power receptacle(see page P.1-2-19).
2. Pull the cassette 1 forward.
3. Draw out Cassette 1 by releasing the
release lever.
Figure 1-2-26
4. Pull the cassette 2 forward.
5. Draw out Cassette 2 by releasing the
release lever.
Figure 1-2-27
Cassette slider 1
Cassette 1
Cassette slider 2
Release lever
Cassette slider 1
Cassette slider 2
Release lever
Cassette 2
To Next Page
