2MN/2N1
1-3-102
U247 Setting the paper feed device
Description
Turns on motor and clutches of paper feeder device.
Purpose
To check the operation of motor and clutches of paper feed device.
Method
1. Press the OK key.
2. Select the paper feed device.
Method: [2PF/Side 2PF]
1. Press the OK key.
2. Select [Motor] or [Device].
3. Select the item to be operated using the Left/Right Select keys.
4. Select [Execute].
5. Press the OK key. The operation starts.
6. To stop operation, press the Back key.
Item No. Description
Display Description
2PF Paper feeder
LCF Large capacity feeder
Side Deck Side deck
SMT Side multi tray
Side 2PF Side paper feeder
Side LCF Side large capacity feeder
Display Description
Motor Off PF paper feed motor (PFPFM) is turned off
On PF paper feed motor (PFPFM) is turned on
Device C1 Clutch PF paper conveying clutch 1 (PFPCCL1) is turned on
C2 Clutch PF paper conveying clutch 2 (PFPCCL2) is turned on
V Feed(H) Clutch PF paper feed clutch 1 (PFPFCL1) is turned on
V Feed(L) Clutch PF paper feed clutch 2 (PFPFCL2) is turned on
Cassette1 Solenoid PF pickup solenoid 1 (PFPUSOL1) is turned on
Cassette2 Solenoid PF pickup solenoid 2 (PFPUSOL2) is turned on
