2MN/2N1
1-3-103
U247 Method: [LCF/Side LCF]
1. Press the OK key.
2. Select [Motor] or [Device].
1. Select the item to be operated using the Left/Right Select keys
2. Select [Execute].
3. Press the OK key. The operation starts.
4. To stop operation, press the Back key.
Method: [Side Deck]
1. Press [Motor] or [Device] and select the item.
2. Select [Execute].
3. Press the OK key. The operation starts.
4. To stop operation, press the Back key.
Item No. Description
Display Description
Motor Off PF paper feed motor (PFPFM) is turned off
On PF paper feed motor (PFPFM) is turned on
Device C1 Clutch PF paper conveying clutch 1 (PFPCCL1) is turned on
C2 Clutch PF paper conveying clutch 2 (PFPCCL2) is turned on
V Feed Clutch PF paper conveying clutch 3 (PFPCCL3) is turned on
H Feed1 Clutch PF paper feed clutch 1 (PFPFCL1) is turned on
H Feed2 Clutch PF paper feed clutch 2 (PFPFCL2) is turned on
Cassette1 Solenoid PF pickup solenoid 1 (PFPUSOL1) is turned on
Cassette2 Solenoid PF pickup solenoid 2 (PFPUSOL2) is turned on
Display Description
Motor Off SF paper feed motor (SFPFM) is turned off
On SF paper feed motor (SFPFM) is turned on
Device C1 Clutch SF paper conveying clutch (SFPCCL) is turned on
Cassette1 Solenoid SF pickup solenoid (PFPUSOL) is turned on
To Next Page
