2MN/2N1-1
1-3-133
U901 1. Select the paper feed location.
2. Select engine counter values when changing the PF main PWB.
Backup the engine counter values to PF.
Select PF counter values when changing the paper feed unit.
Backup the PF counter values to engine.
3. Select [Execute].
4. Press the start key. Back up the counter values.
5. Exit the maintenance mode, perform shut-down, and turn the main power switch to off and on
again. Allow more than 5 seconds between Off and On.
* : The values of cassette 4 counter vary in accordance with the cassette 3 counter.
The values of cassette 7 counter vary in accordance with the cassette 6 counter.
Select [None] if the counter values are not backed up.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
