Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
1-3-43
U053 Setting: [Motor4]
1. Select the item to be adjusted.
*: 55 ppm model only.
Setting: [Motor5]:55 ppm model only
1. Select the item to be adjusted.
Setting: [Motor6]:55 ppm model only
1. Select the item to be adjusted.
Item No. Description
Display Description
Setting
range
Initial setting
45ppm 55ppm
Drum B/W
K
Drum motor K (DRM-K) in
black/white mode
-5000 to 5000 - 25
Drum-
Mono K
Drum motor K (DRM-K) in
monochrome mode
-5000 to 5000 28 22
Display Description
Setting
range
Initial
setting
Dev B/W(K)
Developer motor K (DEVM-K) in black/
white mode
-5000 to 5000 0
Trans B/W Transfer motor (TRM) in black/white
mode
-5000 to 5000 0
Regist B/W Registration motor (RM) in black/white
mode
-5000 to 5000 14
Clean B/W Transfer cleaning motor (TRCM) in
black/white mode
-5000 to 5000 0
Display Description
Setting
range
Initial
setting
SB B/W Eject motor (EM) in black/white mode -5000 to 5000 -16
Fixing B/W Fuser motor (FUM) in black/white
mode
-5000 to 5000 0
Brg1 B/W BR conveying motor 1 (BRCM1) in
black/white mode
-5000 to 5000 -25
Brg2 B/W BR conveying motor 2 (BRCM2) in
black/white mode
-5000 to 5000 -25
Feed B/W Paper feed motor (PFM) in black/white
mode
-5000 to 5000 66
JobSepaB/W JS eject motor (JSEM) in black/white
mode
-5000 to 5000 0
Mid B/W Middle motor (MM) in black/white mode -5000 to 5000 15
DU1 B/W Duplex motor 1 (DUM1) in black/white
mode
-5000 to 5000 -24
DU2 B/W Duplex motor 2 (DUM2) in black/white
mode
-5000 to 5000 -24
