2MN/2N1-1
1-3-94
U241
* : *1: 4000-sheet finisher only. *2: 1000-sheet finisher only.
Method: [Mail Box]
1. Turn each switch or sensor on and off manually to check the status.
When a switch/sensor is detected to be in the ON position, the display for that switch/sensor
will be “1”.
Item No. Description
Display Description
Switch 3 0000000
1 First digit: DF middle tray sensor (DFMTS)
1 Second digit: DF side registration sensor 1 (DFSRS1)
1 Third digit: DF side registration sensor 2 (DFSRS2)
1 Fourth digit: DF bundle discharge sensor (DFBDS)
*1
1 Fifth: DF adjustment sensor (DFADS)
1 Sixth: DF paddle sensor (DFPDS)
*1
1 Seventh: DF shift sensor 1 (DFSFS1)
Switch 4 0000000
1 First digit: DF shift sensor 2 (DFSFS2)
1 Second digit: DF shift release sensor (DFSFRS)
1 Third digit: DF sub tray full sensor (DFSTFS)
1 Fourth digit: DF shift set sensor (DFSFSS)
Display Description
Switch 1 0000000
1 First digit: MB eject sensor (MBES)
1 Second digit: MB cover open/close switch
(MBCOCSW)
1 Third digit: MB overflow sensor 1 (MBOFS1)
1 Fourth digit: MB overflow sensor 2 (MBOFS2)
1 Fifth: MB overflow sensor 3 (MBOFS3)
1 Sixth: MB overflow sensor 4 (MBOFS4)
1 Seventh: MB overflow sensor 5 (MBOFS5)
Switch 2 0000000
1 First digit: MB overflow sensor 6 (MBOFS6)
1 Second digit: MB overflow sensor 7 (MBOFS7)
1 Third digit: MB paper entry sensor (MBPES)
To Next Page
