2MN/2N1
1-2-12
5. Press the guide lock lever to lock.
Figure 1-2-17
6. Insert the paper size plate and the
paper media plate.
7. Gently push the cassette back in.
Figure 1-2-18
Guide lock lever
Paper media plate
Paper size plate
