2MN/2N1
1-5-39
7. Check or replace the transfer roller and
refit all the removed parts.
*: When refitting the transfer roller, con-
firm that the terminal of the ground plate
is in contact with the ground plate in the
frame.
8. When replacing the new transfer roller,
proceed as follows:
1) Performs maintenance mode U127
(clearing the transfer counter) (see
page 1-3-67).
2)Performs maintenance mode U464
(Calibration) (see page 1-3-118).
3)Performs maintenance mode U469
(Auto color registration correction)
(see page 1-3-126).
Figure 1-5-60
Ground plate
Ground plate
(terminal)
Ground plate
(frame)
To Next Page
