Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-4
YC8
1 RESET0 I 0/3.3 V DC Reset signal
Connected to
interface
PWB
2 WAKEUP0 O 0/3.3 V DC Control signal
3 AUDIO0 I Analog Audio signal
4 GND - - Ground
5 USB_DP0 I/O - USB data signal
6 USB_DN0 I/O - USB data signal
7 VBUS0 O 3.3 V DC 3.3 V DC power to IFPWB
8 GND - - Ground
9 RESET1 I 0/3.3 V DC Reset signal
10 WAKEUP1 O 0/3.3 V DC Control signal
11 AUDIO1 I Analog Audio signal
12 GND - - Ground
13 USB_DP1 I/O - USB data signal
14 USB_DN1 I/O - USB data signal
15 VBUS1 O 3.3 V DC 3.3 V DC power to IFPWB
YC9
1 GND - - Ground
Connected to
interface
PWB
2 5V_CUT0 I 0/3.3 V DC 5 V DC cut signal
3 GND - - Ground
4 5V O 5 V DC 5 V DC power to IFPWB
5 GND - - Ground
6 5V_CUT1 I 0/3.3 V DC 5 V DC cut signal
YC12
1
5V O
5 V DC
5 V DC power output
Connected to
operation
PWB
2
LED - - Not used
3
GND - -
Ground
4
C2P_SDAT O
0/3.3 V DC (pulse)
OPWB transmission signal
5
WETCLK - - Not used
6
P2C_SDAT I
0/3.3 V DC (pulse)
OPWB received signal
7
AIRWET - - Not used
8
C2P_MODE1 O
0/3.3 V DC
LCD control signal
9
AIRTEMP - - Not used
10
C2P_MODE2 O
0/3.3 V DC
Buzzer control signal
11
P2C_OK_KEY I
0/3.3 V DC
OK key signal
12
PRESTN O
0/3.3 V DC
Reset signal
13
3.3V O 3.3 V DC 3.3 V DC power output
Connector Pin Signal I/O Voltage Description
