Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-15
YC6
52 DU_SENS I 0/3.3 V DC DUS2: On/Off
Connected to
feed PWB 1
53 BELT_JAM_SENS - - Not used
54 GND - - Ground
55 CLN_SOL_RET O 0/24 V DC CLSOL: On/Off (RET)
56 CLN_SOL_REM O 0/24 V DC CLSOL: On/Off (ACT)
57 REG_SENS_R_S I Analog IDS2 detection signal
58 REG_SENS_R_P I Analog IDS2 detection signal
59 REG_R_LED O Analog IDS2 control signal
60 GND - - Ground
61 REG_SENS_F_S I Analog IDS1 detection signal
62 REG_SENS_F_P I Analog IDS1 detection signal
63 REG_F_LED O Analog IDS1 control signal
64 GND - - Ground
YC7
1 GND - - Ground
Connected to
front PWB
2 WTNR_SET - - Not used
3 INTER_LOCK - - Not used
4 IH_CORE_SENS - - Not used
5 IH_CORE_MOT_
REM
- - Not used
6 IH_CORE_CLK - - Not used
7 WTNR_LED O 0/3.3 V DC (pulse) WTS1 LED emitter signal
8 IH_COIL_FAN_AL
M
I 0/3.3 V DC FUFFM alarm signal
9 IH_COIL_FAN_H O 0/24 V DC FUFFM: On/Off
10 IH_COIL_FAN_L O 0/24 V DC FUFFM: On/Off
11 EXIT_FAN O 0/24 V DC EFFM: On/Off
12 VIB_MOT_REM O 0/24 V DC VM: On/Off
13 JUNC_SOL_REM O 0/24 V DC FSSOL: On/Off (ACT)
14 JUNC_SOL_RET O 0/24 V DC FSSOL: On/Off (RET)
15 GND - - Ground
16 EXIT_MAIN_SEN
S
I 0/3.3 V DC EFS1: On/Off
17 EXIT_FEED_SEN
S
I 0/3.3 V DC SBS: On/Off
18 SB_MOT_REM O 0/3.3 V DC EM: On/Off
19 SB_MOT_PH O 0/3.3 V DC EM control signal
20 SB_MOT_CLK O 0/3.3 V DC (pulse) EM clock signal
Connector Pin Signal I/O Voltage Description
