2MN/2N1
2-3-17
YC8
1SGND - - Ground
Connected to
high voltage
PWB 2
2SGND - - Ground
3 SP_CNT O Analog Separation bias control voltage
4 T2_CNT O Analog Secondary transfer bias control volt-
age
5 T2_OFF_REM O 0/3.3 V DC Separation bias: On/Off
6 T_REM O 0/3.3 V DC Secondary transfer bias: On/Off
7 FB_CONT O 0/3.3 V DC Primary transfer cleaning bias: On/Off
8 T1_CONT_Bk O Analog Primary transfer bias K control volt-
age
9 T1_CONT_M O Analog Primary transfer bias M control volt-
age
10 T1_CONT_C O Analog Primary transfer bias C control volt-
age
11 T1_CONT_Y O Analog Primary transfer bias Y control volt-
age
12 T1_CLR_OFF_RE
M
O 0/3.3 V DC Primary transfer control signal
YC9
1 MOT_CLK O 0/3.3 V DC (pulse) MCPWB clock signal
Connected to
motor con-
trol PWB
2 MOT_SDO O 0/3.3 V DC (pulse) MCPWB serial communication data
signal
3 MOT_SEL O 0/3.3 V DC MCPWB select signal
4 MOT_SDI I 0/3.3 V DC (pulse) MCPWB serial communication data
signal
5 MOT_RDY I 0/3.3 V DC MCPWB ready signal
6 EMERGENCY O 0/3.3 V DC MCPWB control signal
7 BLT_SPEED O 0/3.3 V DC TBLS: On/Off
8 BLT_INDEX - - Not used
9 DRM_INDEX_BK O 0/3.3 V DC DRM-K control signal
10 DRM_INDEX_M O 0/3.3 V DC DRM-M control signal
11 DRM_INDEX_C O 0/3.3 V DC DRM-C control signal
12 DRM_INDEX_Y O 0/3.3 V DC DRM-Y control signal
13 GND - - Ground
14 GND - - Ground
15 +5V O 5 V DC 5 V DC power to MCPWB
16 +5V O 5 V DC 5 V DC power to MCPWB
17 BLT_BRAKE - - Not used
18 BLT_VM - - Not used
Connector Pin Signal I/O Voltage Description
To Next Page
