Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-27
YC19
B13 BELT_FAN1 O 0/24 V DC BLFM1: On/Off
Connected to
paper feeder/
large capac-
ity feeder,
toner fan
motor 1/2,
belt fan
motor 1/2
and exhaust
fan motor 1/2
B14 24V1 O 24 V DC 24 V DC power to BLFM2
B15 BELT_FAN2 O 0/24 V DC BLFM2: On/Off
B16 DLP_FAN1 O 0/24 V DC EXFM1: On/Off
B17 24V1 O 24 V DC 24 V DC power to EXFM1
B18 DLP_FAN2 O 0/24 V DC EXFM2: On/Off
B19 24V1 O 24 V DC 24 V DC power to EXFM2
YC20
1 DECAL_HP - - Not used
Connected to
bridge unit
2 GUIDE_REM - - Not used
3 GUIDE_CLK - - Not used
4 GUIDE_PD - - Not used
5 GUIDE_DIR - - Not used
6 DECAL_REM - - Not used
7 DECAL_PH - - Not used
8 DECAL_CLK - - Not used
9 DECAL_PD - - Not used
10 DECAL_DIR - - Not used
11 24V1 O 24 V DC 24 V DC power to BRSOL
12 MAIL_SOL_REM O 0/24 V DC BRSOL: On/Off (ACT)
13 MAIL_SOL_RET O 0/24 V DC BRSOL: On/Off (RET)
14 GND - - Ground
15 EXIT_COV_OPE
N
I 0/3.3 V DC BRECSW: On/Off
16 GND - - Ground
17 EXIT_SENS I 0/3.3 V DC BRES: On/Off
18 5V O 5 V DC 5 V DC power to BRES
19 5V O 5 V DC 5 V DC power to BRES
20 BRIDGE2 REM O 0/3.3 V DC BRCM2: On/Off
21 BRIDGE2 PH O 0/3.3 V DC BRCM2 control signal
22 BRIDGE2 CLK O 0/3.3 V DC (pulse) BRCM2 clock signal
23 BRIDGE2 PD O 0/3.3 V DC BRCM2 control signal
24 BRIDGE2 DIR O 0/3.3 V DC BRCM2 drive switch signal
25 BRIDGE1 REM O 0/3.3 V DC BRCM2: On/Off
26 BRIDGE1 PH O 0/3.3 V DC BRCM1 control signal
27 BRIDGE1 CLK O 0/3.3 V DC (pulse) BRCM1 clock signal
28 BRIDGE1 PD O 0/3.3 V DC BRCM1 control signal
Connector Pin Signal I/O Voltage Description
