Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-31
YC46
18
HSYNC_AP I
0/3.3 V DC (pulse)
Image control signal
Connected to
main PWB
19
HSYNC_AN I
0/3.3 V DC (pulse)
Image control signal
20
VSYNC_DP I
0/3.3 V DC (pulse)
Image control signal
21
VSYNC_DN I
0/3.3 V DC (pulse)
Image control signal
22
VSYNC_CP I
0/3.3 V DC (pulse)
Image control signal
23
VSYNC_CN I
0/3.3 V DC (pulse)
Image control signal
24
VSYNC_BP I
0/3.3 V DC (pulse)
Image control signal
25
VSYNC_BN I
0/3.3 V DC (pulse)
Image control signal
26
VSYNC_AP I
0/3.3 V DC (pulse)
Image control signal
27
VSYNC_AN I
0/3.3 V DC (pulse)
Image control signal
28
GND
- - Ground
29
SAR_VCLK_P I
0/3.3 V DC (pulse)
Clock signal
30
SAR_VCLK_N I
0/3.3 V DC (pulse)
Clock signal
31
GND
- - Ground
32
SAR_CH3_P I
0/3.3 V DC (pulse)
Image control signal
33
SAR_CH3_N I
0/3.3 V DC (pulse)
Image control signal
34
GND
- - Ground
35
SAR_CH2_P I
0/3.3 V DC (pulse)
Image control signal
36
SAR_CH2_N I
0/3.3 V DC (pulse)
Image control signal
37
GND
- - Ground
38
SAR_CH1_P I
0/3.3 V DC (pulse)
Image control signal
39
SAR_CH1_N I
0/3.3 V DC (pulse)
Image control signal
40
GND
- - Ground
Connector Pin Signal I/O Voltage Description
