Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-35
YC16
1 24V1 O 24 V DC 24 V DC power to HVPWB1
Connected to
high voltage
PWB 1
2 24V1 O 24 V DC 24 V DC power to HVPWB1
3 24V1 O 24 V DC 24 V DC power to HVPWB1
4PGND - - Ground
5PGND - - Ground
6PGND - - Ground
YC17
1 POWER_OFF I 0/3.3 V DC Sleep mode signal: On/Off
Connected to
feed PWB 1
2 DRUM_HEAT_RE
M
I 0/3.3 V DC FH: On/Off
3 GND - - Ground
4
FSR_RELAY_RE
M
--
Not used
Connector Pin Signal I/O Voltage Description
