Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-57
Connector Pin Signal I/O Voltage Description
YC1
1 GND - - Ground
Connected to
engine PWB
2 FEED_MOT_REM I 0/3.3 V DC PFM: On/Off
3 FEED_MOT_CLK I 0/3.3 V DC (pulse) PFM clock signal
4 FEED_MOT_RDY O 0/3.3 V DC PFM ready signal
5 FEED_MOT_DIR I 0/3.3 V DC PFM drive switch signal
6 FEED_CL1_REM I 0/24 V DC PFCL1: On/Off
7 FEED_CL2_REM I 0/24 V DC PFCL2: On/Off
8 ASIST_CL2 I 0/24 V DC ASCL2: On/Off
9 LIFT_MOT2_REM I 0/24 V DC LM2: On/Off
10 GND - - Ground
11 LIFT_MOT1_REM
1
I 0/24 V DC LM1: On/Off
12 CAS2_WID O 0/3.3 V DC PWSW2: On/Off
13 CAS2_LNG3 O 0/3.3 V DC PLSW2: On/Off
14 CAS2_LNG2 O 0/3.3 V DC PLSW2: On/Off
15 CAS2_LNG1 O 0/3.3 V DC PLSW2: On/Off
16 CAS1_WID O 0/3.3 V DC PWSW1: On/Off
17 CAS1_LNG3 O 0/3.3 V DC PLSW1: On/Off
18 CAS1_LNG2 O 0/3.3 V DC PLSW1: On/Off
19 CAS1_LNG1 O 0/3.3 V DC PLSW1: On/Off
20 GND - - Ground
21 CAS2_QUANT2 O 0/3.3 V DC PGS2(L): On/Off
22 CAS2_QUANT1 O 0/3.3 V DC PGS2(U): On/Off
23 CAS1_QUANT2 O 0/3.3 V DC PGS1(L): On/Off
24 CAS1_QUANT1 O 0/3.3 V DC PGS1(U): On/Off
25 LIFT_MOT1_LOC
K
O 0/3.3 V DC LM1 lock signal
26 LIFT_MOT2_LOC
K
O 0/3.3 V DC LM2 lock signal
27 CURRENT_SIG O 0/3.3 V DC Current signal
28 V-FEED_CL I 0/24 V DC PCCL: On/Off
29 COVER_OPEN O 0/3.3 V DC PCCSW: On/Off
30 FEED2_SENS O 0/3.3 V DC PFPCS1: On/Off
31 CAS1_P0 O 0/3.3 V DC FS1: On/Off
32 CAS1_LIFT_UP O 0/3.3 V DC LS1: On/Off
33 GND - - Ground
34 CAS1_EMPTY O 0/3.3 V DC PS1: On/Off
