2MN/2N1
2-3-67
YC16
1 DU1_B/ O 0/24 V DC (pulse) DUM1 drive control signal
Connected to
duplex motor
1 and fuser
fan motor 1/2
2 DU1_A/ O 0/24 V DC (pulse) DUM1 drive control signal
3 DU1_B O 0/24 V DC (pulse) DUM1 drive control signal
4 DU1_A O 0/24 V DC (pulse) DUM1 drive control signal
5 EDGE_FAN_REM O 0/24 V DC FUFM1: On/Off
6 24V2 O 24 V DC 24 V DC power to FUFM1
7 EDGE_FAN_REM O 0/24 V DC FUFM2: On/Off
8 24V2 O 24 V DC 24 V DC power to FUFM2
Connector Pin Signal I/O Voltage Description
