Kyocera ECOSYS FS-C8650DN Service Manual

2MN/2N1
2-3-70
YC4
1 DRM_C_CW/
CCW
O 0/24 V DC DRM-C: On/Off
Connected to
drum motor
C/Y
2 DRM_Y_CW/
CCW
O 0/24 V DC DRM-Y: On/Off
3 DRM_C_LD O 0/3.3 V DC DRM-C control signal
4 DRM_Y_LD O 0/3.3 V DC DRM-Y control signal
5 DRM_C_CLK O 0/3.3 V DC (pulse) DRM-C clock signal
6 DRM_Y_CLK O 0/3.3 V DC (pulse) DRM-Y clock signal
7 DRM_C_Start/
Stop
O 0/3.3 V DC DRM-C control signal
8 DRM_Y_Start/
Stop
O 0/3.3 V DC DRM-Y control signal
9PGND - - Ground
10 PGND - - Ground
11 +24V1 O 24 V DC 24 V DC power to DRM-C
12 +24V1 O 24 V DC 24 V DC power to DRM-Y
YC5
1 DRM_BK_CW/
CCW
O 0/24 V DC DRM-Bk: On/Off
Connected to
drum motor
K/M
2 DRM_M_CW/
CCW
O 0/24 V DC DRM-M: On/Off
3 DRM_BK_LD O 0/3.3 V DC DRM-Bk control signal
4 DRM_M_LD O 0/3.3 V DC DRM-M control signal
5 DRM_BK_CLK O 0/3.3 V DC (pulse) DRM-Bk clock signal
6 DRM_M_CLK O 0/3.3 V DC (pulse) DRM-M clock signal
7 DRM_BK_Start/
Stop
O 0/3.3 V DC DRM-Bk control signal
8 DRM_M_Start/
Stop
O 0/3.3 V DC DRM-M control signal
9PGND - - Ground
10 PGND - - Ground
11 +24V1 O 24 V DC 24 V DC power to DRM-K
12 +24V1 O 24 V DC 24 V DC power to DRM-M
Connector Pin Signal I/O Voltage Description
