2MN/2N1
2-3-75
YC2
55 INT_ST 2 Bk I 0/3.3 V DC APCPWB-K control signal
Connected to
engine PWB
56 INT_ST 1 Bk I 0/3.3 V DC APCPWB-K control signal
57 PALA_SIG P0 Bk I 0/3.3 V DC APCPWB-K control signal
58 PALA_SIG P1 Bk I 0/3.3 V DC APCPWB-K control signal
59 PALA_SIG P2 Bk I 0/3.3 V DC APCPWB-K control signal
60 GAIN FIX Bk I 0/3.3 V DC APCPWB-K control signal
61 SGND - - Ground
62 DATA_2NBk(LVD
S)
I 0/3.3 V DC (pulse) Video data signal K (N)
63 DATA_2PBk(LVD
S)
I 0/3.3 V DC (pulse) Video data signal K (P)
64 SGND - - Ground
YC3
1SGND - - Ground
Connected to
engine PWB
2 BD Y O 0/3.3 V DC (pulse) Horizontal synchronization signal Y
3 LSU_TH Y O Analog LSU thermistor Y detection signal
4 CUALM Y O 0/3.3 V DC APCPWB-Y alarm signal
5 PALA_SIG P3 Y I 0/3.3 V DC APCPWB-Y control signal
6 PALA_SIG P4 Y I 0/3.3 V DC APCPWB-Y control signal
7SGND - - Ground
8 SDCLK Y I 0/3.3 V DC (pulse) APCPWB-Y clock signal
9SGND - - Ground
10 DATA_1N_Y(LVD
S)
I 0/3.3 V DC (pulse) Video data signal Y (N)
11 DATA_1P_Y(LVD
S)
I 0/3.3 V DC (pulse) Video data signal Y (P)
12 SGND - - Ground
13 REM Y I 0/24 V DC PM-Y: On/Off
14 LOCK Y O 0/3.3 V DC PM-Y lock signal
15 CLK Y I 0/3.3 V DC (pulse) PM-Y clock signal
16 SGND - - Ground
17 BD C O 0/3.3 V DC (pulse) Horizontal synchronization signal C
18 LSU_TH C O Analog LSU thermistor C detection signal
19 CUALM C O 0/3.3 V DC APCPWB-C alarm signal
20 PALA_SIG P3 C I 0/3.3 V DC APCPWB-C control signal
21 PALA_SIG P4 C I 0/3.3 V DC APCPWB-C control signal
22 SGND - - Ground
23 SDCLK C I 0/3.3 V DC (pulse) APCPWB-C clock signal
Connector Pin Signal I/O Voltage Description
To Next Page
