2MN/2N1
2-3-77
YC3
57 SGND - - Ground
Connected to
engine PWB
58 REM Bk I 0/24 V DC PM-K: On/Off
59 LOCK Bk O 0/3.3 V DC PM-K lock signal
60 CLK Bk I 0/3.3 V DC (pulse) PM-K clock signal
YC4
1 +24V O 24 V DC 24 V DC power to PM-K
Connected to
polygon
motor K
2PGND - - Ground
3 P_REM Bk O 0/24 V DC PM-K: On/Off
4 P_LOCK Bk I 0/3.3 V DC PM-K lock signal
5 P_CLK Bk O 0/3.3 V DC (pulse) PM-K clock signal
YC5
1SGND - - Ground
Connected to
APC PWB K
2 BD Bk I 0/3.3 V DC (pulse) Horizontal synchronization signal K
3 LSU_TH Bk I Analog LSU thermistor K detection signal
4 PALA_SIG
P3_2Bk
- - Not used
5 LDD_CS 2 Bk - - Not used
6 +5V O 5 V DC 5 V DC power to APCPWB-K
7 +5V O 5 V DC 5 V DC power to APCPWB-K
8 +5V O 5 V DC 5 V DC power to APCPWB-K
9 LDD_CS 1 Bk O 0/3.3 V DC APCPWB-K control signal
10 SDI1 BK I 0/3.3 V DC (pulse) Serial communication data signal
11 SDO1 BK O 0/3.3 V DC (pulse) Serial communication data signal
12 CLK1 BK O 0/3.3 V DC (pulse) APCPWB-K clock signal
13 EEPROM CS 1 Bk I/O 0/3.3 V DC (pulse) APCPWB-K EEPROM data signal
14 MSET_N O 0/3.3 V DC APCPWB-K control signal
15 CUALM Bk I 0/3.3 V DC APCPWB-K alarm signal
16 INT_ST 2 Bk O 0/3.3 V DC APCPWB-K control signal
17 INT_ST 1 Bk O 0/3.3 V DC APCPWB-K control signal
18 PALA_SIG P0 Bk O 0/3.3 V DC APCPWB-K control signal
19 PALA_SIG P1 Bk O 0/3.3 V DC APCPWB-K control signal
20 PALA_SIG P2 Bk O 0/3.3 V DC APCPWB-K control signal
21 PALA_SIG P3 Bk O 0/3.3 V DC APCPWB-K control signal
22 PALA_SIG P4 Bk O 0/3.3 V DC APCPWB-K control signal
23 SDCLK Bk O 0/3.3 V DC (pulse) APCPWB-K clock signal
24 GAIN FIX Bk O 0/3.3 V DC APCPWB-K control signal
