2-110 Service Manual
5062
4
Replace the 2000-sheet high-capacity feeder
jam door clearance sensor. See “2000-sheet
high-capacity feeder jam door clearance
sensor removal” on page 4-188.
Does the problem persist?
Go to step 5. Problem solved.
5
Replace the 2000-sheet high-capacity feeder
lift drive motor assembly. See “2000-sheet
high-capacity feeder lift drive motor
assembly removal” on page 4-201.
Does the problem persist?
Go to step 6. Problem solved.
6
Replace the 2000-sheet high-capacity feeder
pick assembly. See the installation note of
“2000-sheet high-capacity feeder pick
assembly removal” on page 4-207.
Does the problem persist?
Go to step 7. Problem solved.
7
Replace the 2000-sheet high-capacity feeder
drive assembly. See “2000-sheet high-
capacity feeder drive assembly removal”
on page 4-175.
Does the problem persist?
Go to step 9. Problem solved.
8
Replace the 2000-sheet high-capacity feeder
controller card assembly. See “2000-sheet
high-capacity feeder controller card
assembly removal” on page 4-174.
Does the problem persist?
Replace the 2000-sheet
high-capacity feeder input
option.
Problem solved.
Step Questions / actions Yes No
