Repair information 4-221

5062

Installation note:

The right anti-tip latch assembly (A) is thinner compared to the left-anti-tip latch assembly (B).

2000-sheet high-capacity feeder right side cover removal

1. Remove the rear cover. See “2000-sheet high-capacity feeder rear cover removal” on page 4-218.

2. Open the media tray assembly.

3. Remove the seven screws (A) securing the right side cover to the drawer.

A (88A0442)
