Lexmark C792e 5062-210 - Fuser Thermistor Removal

4-66 Service Manual
5062
11. Push in the tab (E) to disconnect the cable from the LVPS, and remove the cable.
Fuser thermistor removal
See “Fuser thermal guide assembly” on page 7-37 for the part number.
1. Remove the fuser. See “Fuser assembly removal” on page 4-58.
2. Disconnect the cable (A).
3. Remove four screws (B) to remove the thermistor.
E
A B (88A0212)
