Parts catalog 7-33
5062
Assembly 13: Miscellaneous
P/N
Units/
FRU
Description Removal procedure
40X7163 5 Sensors parts packet, including
• Waste toner sensors (2)
• Paper auto size sensor
• Paper path sensor (not shown)
• Bin-full sensor (not shown)
“Waste toner sensor removal” on
page 4-148
“Waste toner full sensor removal” on
page 4-151
“Paper auto-size sensor removal” on
page 4-113
“Staging deflector assembly removal”
on page 4-135
“Bin-full sensor removal” on page 4-37
40X7167 1 EP and cartridge cables parts packet,
including
• BLDC K & ITU cable
• BLDC Y & Fuser cable
• BLDC C & M cable
• M+K Cart Metering cable
• C+Y Cart Metering cable
For cable descriptions and locations, see
“Cable and thermistor location table”
on page 7-34.
40X7168 1 Cables parts packet, including
• Paper path
• MPF sensor
• Tray 1 machine side
• Duplex motor
• Staging motor
• Thermistor & redrive
• HVPS cable
• Option bottom
• Ground
• Duplex door beacon side
• Ref edge ground
• Blower & right side waste
• Duplexer
• Waste toner full
40X7169 1 OP panel cables parts packet, including
• Front host USB
• Card reader
• Panel USB
• User interface card
40X7170 1 Beacon cables parts packet, including
• Waste toner
• Bin-full & output beacon
• Front door beacon
40X7171 1 Thermistors parts packet, including
• Thermistor—weather station comp
• Fuser thermal guide assembly
40X7173 140 Screws and fasteners parts packet For screw descriptions and locations, see
“Screw and retainer identification
table” on page 7-38.
40X7175 24 Cable ties parts packet N/A
40X7176 5 Cable retainer parts packet N/A
40X7177 5 Cable retainer parts packet (holds
thermistor on LVPS)
N/A
