Lexmark C792e 5062-210 - 2000-Sheet High-Capacity Feeder Jam Clearance Top Cover Removal

Repair information 4-187
5062
2000-sheet high-capacity feeder jam clearance top cover removal
1. Open the jam clearance cover.
2. Remove the two screws (A) and one screw (B) securing the jam clearance top cover to the drawer.
3. Lift the right side of the jam clearance top cover to clear it from the LED bracket.
A (88A0414) B (88A0231)
