Repair information 4-35

5062

Base printer removals

ACM bias spring removal

See “Left” on page 7-11 for the part number.

1. Remove the paper pick mechanism assembly. See “Paper pick mechanism assembly removal” on

page 4-116.

2. Remove the screw (A) to remove the spring.

A (88A0323)
