Parts catalog 7-11
5062
Assembly 4: Left
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
4—1 40X7133 1 1 Redrive parts packet, including
• Gear thrust washer (2)
• Gear—Idler 50T (2)
• Gear—64T 22T Compound
• Gear—36T 18T Compound
“Redrive gears removal” on
page 4-129
2 40X7166 1 1 ITU autoconnect cable “ITU autoconnect removal” on
page 4-74
3 40X7163 Sensors parts packet, including
• Waste toner sensors (2) (not
shown)
• Paper auto size sensor (not shown)
• Paper path sensors (input, S1,
narrow media, near narrow media)
• Bin-full sensor (not shown)
“Staging deflector assembly
removal” on page 4-135
4 40X7146 1 1 Staging deflector assembly with
sensors
“Staging deflector assembly
removal” on page 4-135
5 40X7172 1 1 Fuser/MPF/autocomp parts packet,
including
• Fuser datum rear bellcrank
• Fuser datum front bellcrank
• Fuser datum bellcrank spring (2)
• Autocomp (ACM) bias spring
• MPF rear breakaway support
• MPF front breakaway support
“Datum bell crank removal” on
page 4-49
“ACM bias spring removal” on
page 4-35
“MPF breakaway assemblies
removal” on page 4-94
6 40X7100 1 1 Fuser assembly, 115 V “Fuser assembly removal” on
page 4-58
40X7101 Fuser assembly, 220 V
40X7102 Fuser assembly, 100 V
7 40X7164 1 1 Lower frame cable cover “Lower frame cable cover removal”
on page 4-15
8 40X7132 1 1 Redrive motor assembly “Redrive motor removal” on
page 4-130
