Diagnostic information 2-113
5062
4
Remove the duplex cable cover.
Check the cable for proper connection.
Is the cable connected correctly?
Go to step 5. Reseat the cable.
5
Check the cable for damage.
Is the cable connected correctly?
Replace the duplexer
cable.
To access the cable, see
“LVPS exit duct removal”
on page 4-85
and
“Left cover removal” on
page 4-10.
Go to step 6.
Step Questions / actions Yes No
