5-12 Service Manual
5062
550-sheet tray option system card
550-sheet tray option system card
connectors
See “550-sheet tray option system card” on page 5-11.
Connector Pin # Signal Pin # Signal
J2
Jam door sensor
1GND
2 Input
3 +5V_Switch
J3
Pick motor
1 +5V_Switch
2 ENCODER
3GND
4 Motor +
5 Motor -
J4
Paper level sensor
1 +5V_Switch
2 P_LEV_SENSOR_1
3GND
4
5 +5V_Switch
6 P_LEV_SENSOR_2
7GND
J10
Feed motor
1 +5V_Switch
2 ENCODER
3GND
4 Motor +
5 Motor -
6
J17
Jam Led
1 JAM_LIGHTPIPE
2 Ground
3 JAM_DOOR_LED
4 Ground
J30
Paper port to next option
1GND
2 PP_RXD
3GND
4 PP_TXD
5 MTR2 ENCODER
6S2
J32
Paper port to printer
1GND
2 PP_RXD
3GND
4 PP_TXD
5S2
