Lexmark C792e 5062-210 - Page 567

Parts catalog 7-7
5062
Assembly 3: Front
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
3—1 40X7145 1 1 ITU contact block assembly “ITU block assembly removal” on
page 4-76
2 40X7130 1 1 Cartridge blower assembly “Cartridge blower assembly
removal” on page 4-37
3 40X7141 4 1 Cartridge rail assembly, including
• Labels Y, C, M, K (2 each)
• Cartridge rail, right side
• Cartridge rail, left side
“Cartridge rail removal” on
page 4-47
4 40X7163 Sensors parts packet, including
• Waste toner sensors (2)
• Paper auto size sensor
• Paper path sensors (not shown)
• Bin-full sensor (not shown)
“Waste toner sensor removal” on
page 4-148
“Waste toner full sensor removal”
on page 4-151
“Paper auto-size sensor removal”
on page 4-113
“Bin-full sensor removal” on
page 4-37
5 40X7161 1 1 Waste toner tray bracket “Waste toner tray bracket removal”
on page 4-152
6 40X7139 1 1 HVPS assembly with cable shield “High-voltage power supply (HVPS)
board removal” on page 4-67
7 40X7112 1 1 Housing interlock assembly with
sensor
“Housing interlock assembly
removal” on page 4-71
8 40X7158 1 1 Staging paper path reference edge
assembly
“Staging paper path reference edge
assembly removal” on page 4-136
