Parts catalog 7-9
5062
Assembly 3.1: Front (continued)
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
3.1—1 40X7142 4 1 Cartridge memory block with sensor “Cartridge memory block removal”
on page 4-42
2 40X7160 1 1 Paper pick mechanism assembly “Paper pick mechanism assembly
removal” on page 4-116
3 40X6104 2 2 Pick tire roll assembly “Pick rolls removal” on page 4-118
4 40X7143 4 1 Cartridge contact block assembly “Cartridge contact block assembly
removal” on page 4-41
5 40X7126 1 1 Media tray rails (1 right, 1 left) “Media tray rail removal” on
page 4-89
To Next Page
