Parts catalog 7-13
5062
Assembly 4.1: Left (continued)
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
4.1—1 40X7134 1 1 Paper path redrive assembly “Paper path redrive assembly with
sensors removal” on page 4-113
2 40X7153 1 1 Left access door pistons parts packet,
including
• Piston clip pin
• Left door spring support
• Piston housing assembly
• Door support anchor pin (3)
“” on page 4-77
3 40X7165 1 1 Fuser system card and LVPS cable
with cable ties
“Fuser system card and LVPS cable
removal” on page 4-63
4 40X7103 1 1 ITU module assembly “ITU assembly removal” on
page 4-72
To Next Page
