Parts catalog 7-21
5062
Assembly 8: Optional 2000-sheet high-capacity feeder
Index P/N
Units/
opt
Units/
FRU
Description Removal procedure
8—1 40X6275 2 2 2000-sheet high-capacity feeder pick
roll assembly
“2000-sheet high-capacity feeder
pick roll assembly removal” on
page 4-214
2 40X6119 1 1 2000-sheet high-capacity feeder pick
assembly
“2000-sheet high-capacity feeder
pick assembly removal” on
page 4-207
3 40X6274 3 3 550-sheet/2000-sheet input option
sensor pack
“2000-sheet high-capacity feeder
pass thru sensor removal” on
page 4-205
and “2000-sheet high-capacity
feeder elevator home sensor
removal” on page 4-179
and “2000-sheet high-capacity
feeder jam door clearance sensor
removal” on page 4-188
4 40X4585 2 1 Tray latch “2000-sheet high-capacity feeder
bellcrank assembly removal” on
page 4-173
5 40X6276 1 1 2000-sheet high-capacity feeder
controller card assembly
“2000-sheet high-capacity feeder
controller card assembly removal”
on page 4-174
6 40X6101 2 2 Anti-tip latch assembly “2000-sheet high-capacity feeder
right anti-tip latch assembly
removal” on page 4-220
and “2000-sheet high-capacity
feeder left anti-tip latch assembly
removal” on page 4-191
7 40X6486 1 1 2000-sheet high-capacity feeder lift
drive motor assembly
“2000-sheet high-capacity feeder lift
drive motor assembly removal” on
page 4-201
8 40X6115 1 1 2000-sheet high-capacity feeder media
tray assembly
“2000-sheet high-capacity feeder
media tray assembly removal” on
page 4-204
9 40X6118 1 1 2000-sheet high-capacity feeder jam
clearance cover
“2000-sheet high-capacity feeder
jam clearance cover removal” on
page 4-183
10 40X6116 1 1 2000-sheet high-capacity feeder drive
assembly
“2000-sheet high-capacity feeder
drive assembly removal” on
page 4-175
