Parts catalog 7-23
5062
Assembly 9: Finisher assembly
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description Removal procedure
9—1 40X7234 1 1 Left access door assembly “Finisher or stacker left access door
assembly removal” on page 4-250
2 40X7238 1 1 Backup redrive roller “Finisher or stacker feed roller
removal” on page 4-247
3 40X7231 1 1 Rear cover “Finisher or stacker rear cover
removal” on page 4-257
4 40X5544 1 1 Sensor (bin full receive) “Finisher or stacker sensor (bin-full
receive) removal” on page 4-258
5 40X7240 1 1 Finisher bin-full spring “Finisher or stacker bin-full spring
removal” on page 4-243
6 40X5727 1 1 LED clear lens “Finisher or stacker standard output
bin LED and LED lens removal” on
page 4-264
7 40X5545 1 1 Standard output bin LED “Finisher or stacker standard output
bin LED and LED lens removal” on
page 4-264
8 40X7239 1 1 Bottom cover “Finisher or stacker bottom cover
removal” on page 4-245
9 40X4618 1 1 Sensor (finisher bin media present) “Finisher or stacker sensor (finisher
bin media present) removal” on
page 4-260
10 40X4619 1 1 Output bin extension “Finisher or stacker output bin
extension removal” on page 4-254
11 40X7241 1 1 Finisher controller card assembly “Finisher or stacker controller card
assembly removal” on page 4-245
12 40X4626 1 1 Sensor (bin full send) “Finisher or stacker sensor (bin-full
send) removal” on page 4-259
13 40X7232 1 1 Front cover “Finisher or stacker front cover
removal” on page 4-248
14 40X7233 1 1 Top cover “Finisher or stacker top cover
removal” on page 4-267
15 40X5906 1 1 Sensor (stapler pass thru) “Finisher sensor (stapler pass thru)
removal” on page 4-262
16 40X7237 1 1 Beacon housing “Finisher or stacker access door
beacon LED and beacon housing
removal” on page 4-243
17 40X7236 1 1 Beacon clear lens “Finisher or stacker left access door
assembly removal” on page 4-250
18 40X7235 1 1 Left access beacon “Finisher or stacker access door
beacon LED and beacon housing
removal” on page 4-243
