Parts catalog 7-31
5062
Assembly 11.1: High-capacity output stacker (continued)
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description Removal procedure
11.1—1 40X7244 1 1 Rear media stack flap “Finisher or stacker media stack
flap and media stack flap actuator
removal” on page 4-251
2 40X7245 1 1 Front media stack flap “Finisher or stacker media stack
flap and media stack flap actuator
removal” on page 4-251
3 40X7243 1 1 LED clear lens “Finisher or stacker output bin LED
and LED lens removal” on
page 4-254
4 40X4622 1 1 Rear tamper motor assembly “Finisher or stacker tamper drive
motor assembly removal” on
page 4-265
5 40X4624 1 1 Tamper recoil spring “Finisher or stacker tamper recoil
spring removal” on page 4-266
6 40X7247 1 1 Tamper front and rear paddle sensor “Finisher or stacker sensor (paddle
HP) removal” on page 4-261
7 40X4623 1 1 Tamper drive belt “Finisher or stacker tamper drive
belt removal” on page 4-265
8 40X4621 1 1 Front tamper motor assembly “Finisher or stacker tamper drive
motor assembly removal” on
page 4-265
9 40X7242 1 1 Output beacon card “Finisher or stacker output bin LED
and LED lens removal” on
page 4-254
10 40X4615 1 1 Paddle drive motor “Finisher or stacker paddle drive
motor assembly removal” on
page 4-255
