Gocator Line Profile Sensors: User Manual

Gocator Web Interface • 219

Measurement Illustration

Width

Measures the width of a groove.

Depth

Measures the depth of a groove as the maximum

perpendicular distance from a line connecting the edge

points of the groove.

Measurements
